Sunset Aluminium Radiator

If you want to warm your living spaces with an elegant look, with elliptical forms we recommend our Sunset aluminum radiator.

It is suitable for all tastes with its Snow white and Silk Patern Black aluminum radiator options.

TECHNICAL SPECIFICATIONS

Performance Data

Height (H) mm	Conn. (C2) mm	Surface m²	Volume lt	Weight kg	Δt=60 kcal/h	Δt=60 Watt	Δt=50 kcal/h	Δt=50 Watt
500	465	0.38	0.14	0.80	87	101	59	69
600	565	0.46	0.17	0.93	91	106	72	84
1800	1765	1.30	0.40	2.45	186	216	146	169

Width & Connections (Sections 4 – 29)

Number of Sections	4	5	6	7	8	9	10	11	12	13	14	15	16	17	18	19	20	21	22	23	24	25	26	27	28	29
Width (W) mm	275	345	415	485	555	625	695	765	835	905	975	1045	1115	1185	1255	1325	1395	1465	1535	1605	1675	1745	1815	1885	1955	2025
H. Connection	355	425	495	565	635	705	775	845	915	985	1055	1125	1195	1265	1335	1405	1475	1545	1615	1685	1755	1825	1895	2035	2035	2105
Centers (C1) mm	365	435	505	575	645	715	785	855	925	995	1065	1135	1205	1275	1345	1415	1485	1555	1625	1695	1765	1835	1905	2045	2045	2115
